Features

100A/125A,600V max, Single phase, 2 or 3200Amps, 600V AC.

Connectors Line and load size #6-350 Cu-AI.

Heavy duty tinned copper jaw with reinforced clip.

C/W center neutral bar.

NEMA 3R type construction 1.2mm thickness(#18 gauge) or 1.5mm thickness (#16 gauge)galvanized steel sheet, electrostatically appliedepoxy baked gray powder finished.

Ample gutter space for easy wiring.

Convenient knockouts in the side back andbottom.

Lay in type terminal with pressure plates foreasy connections.

The fixed hub size 1/ 2" to 2-1/ 2" for option.
